MANN+HUMMEL · Submerged vacuum-driven ultrafiltration
Product Information
Dimensional notes: Element dimensions follow the manufacturer's drawing: B is length, C is diameter, and A is the permeate outlet diameter. No ±1 mm dimensional tolerance is stated in the supplied datasheet.
A submerged, backwashable spiral-wound UF element with open feed channels, aeration and periodic backwashing for highly fouling water and wastewater streams.
Membrane & element specifications
| Parameter | Specification |
|---|---|
| Membrane | Ultrafiltration |
| Membrane chemistry | PES |
| Construction | Submerged, negative pressure ultrafiltration module |
| Pore size | 0.03 µm |
| Feed channel | 90 mil corrugated |
| Membrane area | 27.4 m² (295 ft²) |
Operating parameters
| Parameter | Specification |
|---|---|
| Transmembrane pressure range | 0.07–0.7 bar (1–10 psi) |
| Temperature range² | 1–45 °C (34–113 °F) |
| pH range² | 2.0–11.0 |
| Applicable air scour rate | 5.6 Nm³/hr (3.5 scfm) |
| Cleaning chlorine tolerance | 1,000 mg/L |
| Maximum feed TSS¹ | 1,000 mg/L |
| Maximum feed oil and grease¹ | 100 mg/L |
Physical dimensions
| Parameter | Specification |
|---|---|
| Dimension A | 47.2 mm (1.9 in) |
| Dimension B | 1,174.0 mm (46.2 in) |
| Dimension C | 273.0 mm (10.8 in) |
| Element weight | 35 kg (77 lbs) |
Important qualifications
- ¹ Depending on feed water quality and operating conditions.
- ² Temperature, pH limits and cleaning procedures are further detailed in the SpiraSep 1060 Product Manual.
Start-up, cleaning & storage
The manufacturer recommends an operational sequence incorporating permeate production, cleaning and module draining. Clean routinely via backwash, chemically enhanced backwash (CEB) and clean-in-place (CIP) to ensure proper operation and prevent membrane damage. Store appropriately to ensure proper operation and prevent membrane damage.
Manufacturer datasheet
spirasep-1060-uf-data-sheet.pdf · Rev. 2408 · Pages 1–2. Specifications and units above follow the supplied manufacturer document.
The co-branded edition adds BioProcessH2O contact details while retaining the manufacturer's technical content.
